WOCD

Email Catalog Product Category Catalog
  • 1428-wocd-nylon

    1428

  • 1458

  • 1555-wocd-plastic

    1555

  • 1740FM

  • 1761-wocd-plastic

    1761

  • 1761A

  • 1761B

  • 1764

  • 1766-wocd-zinc

    1766

  • 1766-1-wocd-zinc

    1766-1

  • 1766A

  • 1773-wocd-zinc

    1773

  • 1775FM-wocd-nylon

    1775FM

  • 1775SM-wocd-zinc

    1775SM

  • 1779FM-wocd-zinc

    1779FM

  • 1779SM-wocd-plastic

    1779SM

  • 1780FM

  • 1781-wocd-aluminum

    1781

  • 1781A

  • 1782

  • 1783

  • 1787-wocd-nylon

    1787

  • 1788A

  • 1789A-L/R

  • 1791

  • 1793-L-B

  • 1793-R-B

  • 1794-wocd-zinc

    1794

  • 1795

  • 1796

  • 1798

  • 1799

  • 1800-L/R

  • 1428

  • DESCRIPTION:
    Spacer, used for 1775FM/ 1775SM/ 1779FM/ 1779SM
  • Patented
1428-wocd-nylon
pdf_dowload

Please login to download CAD files.

  • 1458

  • DESCRIPTION:
    Limit control device housing, match with 1789-L/R
  • Patent Pending
pdf_dowload

Please login to download CAD files.

  • 1555

  • DESCRIPTION:
    Bracket for 17XX wocd
  • MATERIAL: PLASTIC
  • Patent Pending
1555-wocd-plastic
pdf_dowload

Please login to download CAD files.

  • 1740FM

  • DESCRIPTION:
    Face mounted dual action WOCD. Intended for aftermarket field applications.
pdf_dowload

Please login to download CAD files.

  • 1761

  • DESCRIPTION:
    Window opening control device, in-slot mount, fit in thin slot .285" x 1.892", fit 1.3mm to 2.1mm wall thickness. used in vinyl window
  • Patented
1761-wocd-plastic
pdf_dowload

Please login to download CAD files.

  • 1761A

  • DESCRIPTION:
    Single action routed in Tilt latch.
pdf_dowload

Please login to download CAD files.

  • 1761B

  • DESCRIPTION:
    Single action routed in WOCD.
  • TYPE: routed in, single action
pdf_dowload

Please login to download CAD files.

  • 1764

  • DESCRIPTION:
    Dual action routed in tilt latch.
pdf_dowload

Please login to download CAD files.

  • 1766

  • DESCRIPTION:
    Window opening control device, zinc, in-slot mount, 2 screw holes, fit in thin slot .323" x 1.878", used in wood window
  • MATERIAL: ZINC
  • KIT: 702, 705
  • Patented
1766-wocd-zinc
pdf_dowload

Please login to download CAD files.

  • 1766-1

  • DESCRIPTION:
    Single Action,Window opening control device, zinc, in-slot mount, 2 screw holes, fit in thin slot .323" x 1.878", used in wood window, with screw 10115 2pcs included
  • MATERIAL: ZINC
  • Patented
1766-1-wocd-zinc

  • 1766A

  • DESCRIPTION:
    Dual action WOCD, screw in.
  • TYPE: dual action
pdf_dowload

Please login to download CAD files.

  • 1773

  • DESCRIPTION:
    Window opening control device, in-slot mount, with a taller tongue than 1761, fit in thin slot .285" x 1.892", fit 1.3mm to 2.1mm wall thickness, used in vinyl window
  • Patented
1773-wocd-zinc
pdf_dowload

Please login to download CAD files.

  • 1775FM

  • DESCRIPTION:
    Window opening control device for after-market usage, face mount, handed, split version
  • Patented
1775FM-wocd-nylon
pdf_dowload

Please login to download CAD files.

  • 1775SM

  • DESCRIPTION:
    Window opening control device for after-market usage,side mount
  • Patented
1775SM-wocd-zinc
pdf_dowload

Please login to download CAD files.

  • 1779FM

  • DESCRIPTION:
    Window opening control device for after-market usage, face mount, handed, dual action, only one needed per window. Available in left or right handed
  • Patented
1779FM-wocd-zinc
pdf_dowload

Please login to download CAD files.

  • 1779SM

  • DESCRIPTION:
    Window opening control device for after-market usage, side mount, handed, dual action. available in left or right handed
  • Patented
1779SM-wocd-plastic
pdf_dowload

Please login to download CAD files.

  • 1780FM

  • DESCRIPTION:
    Aftermarket face mount dual action WOCD device. Intended for field applications.
  • TYPE: aftermarket, dual action, face mount
pdf_dowload

Please login to download CAD files.

  • 1781

  • DESCRIPTION:
    Window opening control device, slot size is 1.875 x .285 x .689
  • Patented
  • PROPRIETARY: Y
1781-wocd-aluminum
pdf_dowload

Please login to download CAD files.

  • 1781A

  • DESCRIPTION:
    Single Action routed in WOCD.
  • TYPE: single action
pdf_dowload

Please login to download CAD files.

  • 1782

  • DESCRIPTION:
    Aftermarket face mounted WOCD intended for field applications.
pdf_dowload

Please login to download CAD files.

  • 1783

  • DESCRIPTION:
    Single action routed in WOCD.
  • TYPE: single action
pdf_dowload

Please login to download CAD files.

  • 1787

  • DESCRIPTION:
    Window opening control device, with holder for left and right jamb pockets
  • MATERIAL: NYLON
  • Patent Pending
1787-wocd-nylon
pdf_dowload

Please login to download CAD files.

  • 1788A

  • DESCRIPTION:
    Single action routed in WOCD
  • TYPE: single action
pdf_dowload

Please login to download CAD files.

  • 1789A-L/R

  • DESCRIPTION:
    Dual action routed in WOCD.
  • TYPE: dual action
pdf_dowload

Please login to download CAD files.

  • 1791

  • DESCRIPTION:
    Single action routed in WOCD.
  • TYPE: single action
pdf_dowload

Please login to download CAD files.

  • 1793-L-B

  • DESCRIPTION:
    Window opening control device, single-action WOCD with balance cover
  • MATERIAL: NYLON
  • Patent Pending
pdf_dowload

Please login to download CAD files.

  • 1793-R-B

  • DESCRIPTION:
    Window opening control device, single-action WOCD with balance cover
  • MATERIAL: NYLON
  • Patent Pending
pdf_dowload

Please login to download CAD files.

  • 1794

  • DESCRIPTION:
    Dual action window opening control device(WOCD) verson of 1766 with same slot size as 1766 (1.89 x .323 x .650")
  • Patent Pending
1794-wocd-zinc
pdf_dowload

Please login to download CAD files.

  • 1795

  • DESCRIPTION:
    Jamb mounted WOCD, single action.
pdf_dowload

Please login to download CAD files.

  • 1796

  • DESCRIPTION:
    Single action routed in WOCD.
  • TYPE: single action
pdf_dowload

Please login to download CAD files.

  • 1798

  • DESCRIPTION:
    Dual action routed in WOCD. Only one needed per sash.
pdf_dowload

Please login to download CAD files.

  • 1799

  • DESCRIPTION:
    Dual Action routed in WOCD.
  • TYPE: dual action
pdf_dowload

Please login to download CAD files.

  • 1800-L/R

  • DESCRIPTION:
    Casement Window Opening Control Device (WOCD) Pat. Pending
  • TYPE: wocd
