PART #

MATERIAL

F.E.R.

CENTERLINE

SET BACK

TYPE

Uncategorized

1036
DESCRIPTION:
SCREEN CORNER,0.19"X0.40" (604-BLACK)

1036-uncategorized-composite

1038
DESCRIPTION:
PLASTIC SCREEN CORNER,FLANGED,TABBED,RIGHT(L-BROWN)
KIT: 005-L, 005-R

1038-uncategorized-plastic

10383
DESCRIPTION:
PLASTIC SCREEN CORNER,FLANGED,RIGHT(A-BRONZE)

10383-uncategorized-plastic

1040S-41B
DESCRIPTION:
3/4" JAMB ADJUSTER ASSY, 0.407" NUT, 0.75" SCREW(C-EUROE WHITE)

1040S-41B-uncategorized-plastic

10451
DESCRIPTION:
EXTRUDED SCREEN CORNER WITH STOP(K-GREY)

10451-uncategorized-plastic

10452
DESCRIPTION:
EXTRUDED SCREEN CORNER WITHOUT STOP(F-BEIGE)

10452-uncategorized-plastic

1065
DESCRIPTION:
SCREEN TRIGGER LEFT(J-EURO WHITE)

1065-uncategorized-aluminum

1111
DESCRIPTION:
DH SILL CORNER, RIGHT

1111-uncategorized-stainlesssteel

1112
DESCRIPTION:
DH HEAD CORNER, RIGHT

1112-uncategorized-stainlesssteel

1139
DESCRIPTION:
ROLLER,SINGLE,PLASTIC HOUSING,STAINLESS STEEL BEARING,LEFT(BLACK)

1139-uncategorized-plastic

1233
DESCRIPTION:
WEEP HOLE COVER - 3 MOUNTING TABS, BEIGE

1233-uncategorized-plastic

1422
DESCRIPTION:
LIFT/PULL HANDLE, P-BEIGE(SV BEIGE)

1422-uncategorized-plastic

1521
DESCRIPTION:
WELD CORNER SUPPORT,RIGHT(V-BEIGE)701366BG

1521-uncategorized-zinc

1529
DESCRIPTION:
Fix Panel Bracket

1529-uncategorized-plastic

1690A
DESCRIPTION:
PATENT PENDING HINGES (TRACK AND ARMS)

1690A-uncategorized-nylon

1690B
DESCRIPTION:
PATENT PENDING HINGES (TRACK AND ARMS)

1690B-uncategorized-nylon

1766-2
DESCRIPTION:
Window opening control device, zinc, in-slot mount, 2 screw holes, fit in thin slot .323" x 1.878", used in wood window

1766-wocd-zinc

1955
DESCRIPTION:
DUST PLUG,#6 HOLE,LEFT(S-BEIGE)

1955-uncategorized-plastic

1956
DESCRIPTION:
TRACK FILLER,LEFT(V-BEIGE)

1956-uncategorized-plastic

2230
DESCRIPTION:
RAIL END CAP,LEFT(C-EURO WHITE)

2230-uncategorized-nylon

2232
DESCRIPTION:
REVOLUTION BOW PLUG,LEFT

2232-uncategorized-stainlesssteel

2234
DESCRIPTION:
Revolution Bow Plug, right, mat'l PA6+15%GF+Anti UV(BLACK)

2234-uncategorized-zinc

2260
DESCRIPTION:
RAIL END CAP,LEFT(BLUE WHITE)

2260-uncategorized-zinc

2262
DESCRIPTION:
SILL INSERT END CAP, LEFT(BEW) US014801

2262-uncategorized-stainlesssteel

2271
DESCRIPTION:
Rail end cap, ABS

2271-uncategorized-plastic

Please login to download CAD files.

2275
DESCRIPTION:
Rail end cap, non-handed

2275-uncategorized-plastic

Please login to download CAD files.

24022
DESCRIPTION:
REVOLUTION END CAP BODY,RIGHT

24022-uncategorized-zinc

2412
DESCRIPTION:
OUTER SIDERAIL END CAP,RIGHT(BLACK)(35540700 )

2412-uncategorized-zinc

2413
DESCRIPTION:
REVOLUTION END CAP TIP,LEFT

2413-uncategorized-zinc

2810
DESCRIPTION:
LEGEND LH LOWER TILT LTCH 557995

2810-uncategorized-zinc

2820
DESCRIPTION:
(US000123) TOP LH LATCH (113-BEIGE)

2820-uncategorized-nylon

Please login to download CAD files.

2987
DESCRIPTION:
1/2' SHOE FOR CONSTANT FORCE BALANCE

2987-uncategorized-stainlesssteel

3165JD
DESCRIPTION:
SWEEP LOCK,2.25" C/L,0.25" THROW,0.38" SETBACK,#10 SCREW(BLACK)

3165JD-uncategorized-zinc

3177KR
DESCRIPTION:
SWEEP LOCK,2.25" C/L,0.53" THROW,0.39" SETBACK,#10 SCREW WITH KR LOGO(BEIGE)

3177KR-uncategorized-zinc

3193CS
DESCRIPTION:
SWEEP LOCK,2.25" C/L,0.35" THROW,0.39" SETBACK,#10 SCREW WITH CS LOGO(BLUE WHITE)(P35-W001)

3193CS-uncategorized-nylon

5106
DESCRIPTION:
Strike plate, stainless steel
MATERIAL: STAINLESS STEEL
TYPE: Strike Plate

5106-uncategorized-nylon

5210
DESCRIPTION:
JAMB CLIP FOR COBALT

5210-uncategorized-plastic

680DJ
DESCRIPTION:
Sash Lock

680DJ-uncategorized-composite

690SMT
DESCRIPTION:
Sash lock, engraved logo "Simonton", surface mount, 2.25" C/L, .838" set back, #6 screw, FER= Forced Entry Resistance
MATERIAL: ZINC
F.E.R. (Forced Entry Resistant): Y
CENTER LINE: 2.25
SET BACK: 0.838
PATENTED: Y

690SMT

6921
DESCRIPTION:
ALUMINUM SASH PIVOT ASSEMBLY,LEFT

6921-uncategorized-aluminum

6922
DESCRIPTION:
ALUMINUM LOCKING SASH PIVOT ASSEMBLY,RIGHT

6922-uncategorized-zinc

6934
DESCRIPTION:
PIVOT PIN

6934-uncategorized-aluminum

6971
DESCRIPTION:
PIVOT BAR,ZINC DIE CAST,LEFT

6971-uncategorized-zinc

6987
DESCRIPTION:
PIVOT BAR,ZINC DIE CAST,RIGHT

6987-uncategorized-zinc

6989
DESCRIPTION:
PIVOT BAR,ZINC DIE CAST,RIGHT

6989-uncategorized-zinc

9327-1
DESCRIPTION:
DDH KEEPER WHT P/N 2382710 WHIT SCREWS

9327-keepers-zinc

9722FC
DESCRIPTION:
SASH LOCK,SURFACE MOUNT,2.062" C/L,0.688" SET BACK,#6 SCREW,LOW PROFILE,NON HOODED(L-BLUE WHITE)

9722FC-uncategorized-nylon

9722FC-KBW
DESCRIPTION:
SASH LOCK,SURFACE MOUNT,2.062" C/L,0.688" SET BACK,#6 SCREW,LOW PROFILE,NON HOODED(L-BLUE WHITE)

9722FC-uncategorized-nylon

9811-1
DESCRIPTION:
DDH LOCK SATIN NICKL P/N 2382704 WITH SCREWS

9811-locks-plastic

Metal Color Chips

Plastic Color Chip

PM538SS

PM538SS
